Bottom Floor Hinge Chrome

Bottom Floor Hinge

Upgrade your frameless glass door system with our Bottom Floor Pivot Hinge – Polished Chrome, built for smooth operation, clean design, and long-lasting durability. This hydraulic bottom patch fitting delivers controlled self-closing performance while adding a sleek chrome finish that pairs perfectly with modern commercial and residential glass installations.

Ideal for office entrances, retail spaces, interior glass partitions, wine rooms, and contemporary fit-outs, this bottom floor hinge integrates seamlessly with patch fittings, transom fittings, and ladder pulls. The polished chrome finish provides a bright, professional look that enhances any frameless glass door setup.

Precision Performance for High-Traffic Areas

Manufactured with tight precision tolerances, this hydraulic pivot hinge ensures consistent and smooth door movement.

Designed to support:

• Glass Thickness: 10mm (3/8”) and 12mm (1/2”) tempered glass

• Maximum Door Weight: 100 kg (220 lbs)

• Maximum Door Width: 39” (1000 mm)

The built-in hydraulic system includes two adjustable closing speed settings, allowing fine-tuning for optimal door control. The self-closing (non-hold open) function ensures the door safely returns to the closed position after each use.

Flexible Installation

An adjustable bottom plate allows for easier alignment during installation, helping installers achieve precise positioning on-site. Glass fabrication is required—please refer to PDF technical drawings for accurate cut-out specifications before production.

Strong & Corrosion-Resistant Construction

Made from Grade 304 stainless steel with precision components and a high-quality aluminum cover plate, this bottom floor pivot hinge is suitable for both interior and exterior applications. The polished chrome finish offers durability while maintaining a clean, contemporary appearance.

Key Features

• Hydraulic bottom patch fitting for frameless glass doors

• Polished chrome finish

• Compatible with 10mm & 12mm tempered glass

• Supports doors up to 100 kg (220 lbs)

• Maximum door width: 39” (1000 mm)

• Dual adjustable closing speeds

• Self-closing (non-hold open) design


• Grade 304 stainless steel construction

• 5-year warranty

For technical support, feel free to contact our team.
